1 ton truck steering axle Material:45
Tonnage:1T
Distance between kingpins:1165~1360
Distance between leaf springs:650~780
Kingpin diameter:φ25
Kingpin Inclination:7.5°
Drop:23~60
Brake specification:Φ280~320
Rim mounting face distance:1215~1600

3.5 ton truck steering axle Material:40Cr
Tonnage:3.5 T
Distance between kingpins:1630
Distance between leaf springs:800
Kingpin diameter:φ32
Kingpin Inclination:8°
Drop:95
Brake specification:Φ320~360
Rim mounting face distance:1900~2224

4 ton truck steering axle Material:45
Tonnage:4 T
Distance between kingpins:1727
Distance between leaf springs:851~890
Kingpin diameter:φ38
Kingpin Inclination:7°
Drop:74
Brake specification:Φ400
Rim mounting face distance:2204

2.2 ton truck axle Material : 42CrMo
Rated load : 2.2T
Distance between kingpins:1490
Distance between leaf springs:850
Kingpin diameter:φ35
Kingpin Inclination:7°
Drop:89
Brake specification:Φ250*45
Rim mounting face distance:1980

6.5ton truck axle Material : 42CrMo
Rated load : 6.5T
Distance between kingpins:1800.8
Distance between leaf springs:850
Kingpin diameter:φ52
Kingpin Inclination:7°
Drop:89
Brake specification:Φ430*45
Rim mounting face distance:2410.7

9ton truck axle Material:42CrMo
Rated load:9T
Distance between kingpins:1770
Distance between leaf springs:850
Kingpin diameter:φ52
Kingpin Inclination:6°
Drop:89
Brake specification:Φ420*180
Rim mounting face distance:2372

1.5 ton I-BEAM Material:45#
Rated load:1.5T
Distance between kingpins:1354
Distance between leaf springs:710
Kingpin diameter:φ25
Kingpin Inclination:7.5°
Drop:64+8

2.2 ton I-BEAM Material:45#
Tonnage:2.2T
Distance between kingpins:1359
Distance between leaf springs:750
Kingpin diameter:φ30
Kingpin Inclination:7.5°
Drop:64+5

2.5 ton I-BEAM Material:45#
Tonnage:2.5T
Distance between kingpins:1472.4
Distance between leaf springs:760
Kingpin diameter:φ32
Kingpin Inclination:8°
Drop:70+34

Truck Seat-copilot

Truck Seat-Driver

7.5 ton I-BEAM Material:42CrMo
Tonnage:7.5T
Distance between kingpins:1767
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:3°
Drop:89

5.5 ton I-BEAM Material:42CrMo
Tonnage:5.5T
Distance between kingpins:1853.3
Distance between leaf springs:850
Kingpin diameter:φ47
Kingpin Inclination:7°
Drop:φ16

4.2 ton I-BEAM Material:45
Tonnage:4.2T
Distance between kingpins:1727
Distance between leaf springs:851
Kingpin diameter:φ38
Kingpin Inclination:7°
Drop:φ14

7.5 ton truck steering axle Material:42CrMo
Tonnage:7.5T
Distance between kingpins:1767
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:3°
Drop:89
Brake specification:Φ420
Rim mounting face distance:2343~2365

5.5 ton truck steering axle Material:42CrMo
Tonnage:7.5T
Distance between kingpins:1767
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:3°
Drop:89
Brake specification:Φ420
Rim mounting face distance:2343~2365

5 ton truck steering axle Material:42CrMo
Tonnage:4.5~6.1T
Distance between kingpins:1820
Distance between leaf springs:850
Kingpin diameter:φ45
Kingpin Inclination:6.5°
Drop:100
Brake specification:Φ400
Rim mounting face distance:2219~2368

4.3 ton truck steering axle Material:45
Tonnage:4.3T
Distance between kingpins:1727
Distance between leaf springs:851~900
Kingpin diameter:φ38
Kingpin Inclination:7°
Drop:74
Brake specification:Φ400
Rim mounting face distance:2204~2268

3 ton truck steering axle Material:40Cr
Tonnage:3T
Distance between kingpins:1530
Distance between leaf springs:800
Kingpin diameter:φ32
Kingpin Inclination:8°
Drop:95
Brake specification:Φ320~360
Rim mounting face distance:1893~2224

2 ton truck steering axle Material:45
Tonnage:2T
Distance between kingpins:1359
Distance between leaf springs:760
Kingpin diameter:φ30
Kingpin Inclination:7.5°
Drop:64
Brake specification:Φ280~320
Rim mounting face distance:1620~1880
